| Category | Parameter / Component | Specifications & Details |
|---|---|---|
| Dimensions | Size | 10FT/20FT/40FT Customized |
| Parameter Indicators | Fire Resistance | Class A |
| Wind Resistance Performance | 0.50kN/m2 | |
| Life | Over 35 years | |
| Seismic Performance | Level 8 | |
| Main Frame | Finish Treatment | Galvanized formed beam, Electrostatic spray paint treatment, traffic white, thickness ≥ 80 y m |
| Bare Steel Actual Thickness | 2.5mm/2.25mm/1.95mm/1.75mm(±0.01) | |
| Top Frame | Long beam & Short beam: Galvanized beam, width 160mm | |
| Bottom Frame | Long beam & Short beam: Galvanized beam, width 160mm | |
| Steel Column & Bolts | Column: Galvanized column, width 160mm x160mm; Bolt: High strength carriage bolt | |
| Turning Accessories | 160mm*160mm, Actual Thickness: 3.5mm/3.0mm(±0.01) | |
| Square Tube | Chassis Purlin | 50 *100 galvanized square tube (Actual Thickness: 1.2mm/1.1mm/1.0mm) & 20 * 40 galvanized square tube (Actual Thickness: 1.0mm/0.7mm) |
| Top Purlin | 50 * 50 (Actual Thickness: 1.4mm/1.2mm), 40 * 60 (Actual Thickness: 1.0mm/0.8mm), 40 *40 (Actual Thickness: 1.0mm/0.8mm) | |
| Door Frame Pillar | 20 * 40 galvanized square tube, Actual Thickness: 1.0mm/0.7mm(±0.01) | |
| Structure & Fitting | Pressure Plate Groove | Irregular parts, Actual Thickness: 1.0mm/0.7mm(±0.01) |
| Wallboard | 50mm/75mm/100mm foam board, rock wool, silicon rock board, 0.25mm/0.30mm/0.4mm steel plate | |
| Door | Steel door, Wg30mm x H2035mm, 0.3mm/0.25mm steel plate(±0.01) | |
| Window | Sliding window, W925mm x H1200mm, single glass | |
| Floor | 18mm fireproof fiberglass board | |
| Roof Tiles | Thickness ≥ 0.40mm | |
| Ceiling Tiles | Thickness ≥ 0.20mm | |
| Thermal Insulation Cotton | 50mm glass fiber insulation cotton | |
| Auxiliary Materials | Standard includes all screws, structural adhesives, etc. | |
| Circuit | Adapt power supply according to different countries and regions |
